NUTT pre-blead 4 piston hydraulic set, Front right/Rear right side calipers
Caliper sides stated are correct and accurate when you are standing on your scooter.
If you are having trouble identifying which direction callipers you need, contact us with your scooter model and we will tell you what you must buy.
Measurements of the front brake cable is about 130cm and the rear is about 200cm approx.
NUTT hydraulic oil e-scooter brake system is a top rank quality brake system made in Taiwan.
You would get a brake set witch offer much better stopping force, are more durable, and instant response. They are pre-blead and when installed they are complete sealed, moist and/or dirt cannot get into the brake line.
Features:
* Rear brake oil tube: 200cm approx.
* Front brake oil tube: 130cm approx.
* Weight Front Brake: About 327.4gr
* Weight Rear Brake: About 330gr
* Callipers fitted with 4 piston vented brake pads.
Advice:
* Depending on the rotors your vehicle already has on you might need to change the calliper mount brackets or you might just need to add some washers so the calliper will be mounted higher.
* After having them installed for some time and the brake lever gets lose, there is a regulator on the lever and when tighten it the lever will become harder again. If it keeps lose even after regulating the lever or you see that you've lost the braking you used to have then these are the things to check:
1. Brake pads might have worn down
2. Hydraulic brake line is not 100% sealed and fluid is leaking
3. Air has been seeped into the hydraulic chamber.If it’s not just your brake pads that need be replaced then you might need to bleed the brake set. If you are comfortable enough to do it yourself you should look for video on Google. If not then we advise that you seek for professional help. NUTT uses mineral oil (NOT SYNTHETIC).
Here are some of the scooter models that you can fit the Nutt brake sets:
#Kugoo G-Booster, #Kugoo ES3, #Dualtron Ultra, #Ultron11, #FLJ T113, #Beast, #Rebel, #Janobiket10, #Speedway V2, #Kugoo M4pro, #Kugoo G2pro
and possible many more but keep in mind that you might need to replace the brackets or add washers depending of what rotors you have on.
Note that it is your responsibility to make sure that they will fit on your scooter, before buying them.
There are no further instructions on how to fit them so if you still not sure that you can fit them then we strongly suggest that you seek for professional help.
